Digital Laser Measure Module With RS232

Payment Type: T/T,Paypal,Western Union
Incoterm: FOB
Min. Order: 1 Piece/Pieces
Delivery Time: 3 Days

Basic Info

Model No.: B605B

Additional Info

Packaging: 16pcs/plate, 10 plates/ctn

Productivity: 10000pcs/day

Brand: JRT

Transportation: Air

Place of Origin: Chengdu

HS Code: 90318000

Port: Chengdu,Shenzhen

Product Description

Digital Laser Measure Module With RS232
150m Laser Sensor Module has been widely used to industries. The resolution of our 605B laser distance meter snesor is 1mm, with measuring range from 0.03 to 150 metres.  If users needed, we can also connect RS485 RS232 USB laser distance sensor for them.

Parameters:

Accuracy

±3 mm

Measuring Unit

meter/inch/feet

Measuring Range (without Reflection)

0.03-150m

Measuring Time

0.1~3 seconds

Laser Class

Class II

Laser Type

620-690nm, <1mW

Size

72*40*18mm (±1 mm)

Weight

About 25g

Voltage

DC2.0~3.3V

Electrical Level

TTL/CMOS

Frequency

8Hz

Operating Temperature

0-40  (32-104  )

Storage Temperature

-25~60   (-13~140 )

Note: 1. Under bad measure condition, like environment with strong light or the diffuse reflectance of measuring point over-high or low, the accuracy would have bigger amount of error:  ±3 mm+40PPM.

2. Under strong light or bad diffuse reflectance of target, please use a reflection board

3. Operating temperature -10 ℃~40 ℃ can be customized.

Applications:


details

Laser Tape Application


Why Us

1.     Quality. Thanks to our strong R&D team, JRT Laser distance meter and modules have been keeping the pace with the measuring technical evolving and pioneering the industry with the unique and patented laser phase measuring solution. From the view of Accuracy, Range, Resolution, Stability, Size and Power Consumption, JRT is undoubtedly one of the best in the line.

2.    Schemes of single transmit and single receive. This is one of our patents. We are the only one in the market have this technology. It helps us to reduce our cost and power consumption a lot.

3.     Accuracy and Range. Our typical accuracy is ±1.0mm, and range from 40m to 150m.

4.     Stability. Our laser distance meter and distance module have a high stability, especially for industry use.

5.     Materials. We use the high performance price ratio components to guarantee the high quality along with a low price.

6.     Service. All goods will be inspected and tested before shipment and have one year guarantee and a life-time after sales service. Thirdly, customers` satisfaction is the most important thing to us. If you have any problems or questions, please contact us by Trademanager, email, WhatsApp, Skype, telephone. You will get your respond within 12 hours on working days, 24 hours on holidays.

7.     Size. We are keeping research on size of our laser distance module, the smallest size is: 45*25*12mm, 10g for now. We are R&D a new module the size is as small as a pen.
